COOLER MASTER Ház Mid ATX QUBE 500 FLATPACK BLACK EDITION, 1db Ventilátorral, Tápegység nélkül, fekete

• Részletek
• Adatok

Részletek

Model Number QUBE 500 Flatpack: Q500-KGNN-S00, QUBE 500 Flatpack White: Q500-WGNN-S00

Exterior Color White, Black

Materials - Exterior Steel, Plastic, Tempered Glass

Materials - Left Side Panel Grey TG + Steel

Dimensions (L x W x H) 406 x 231 x 415mm (Incl. Protrusions), 380 x 231 x 381mm (excl. Protrusions)

Volume 33.44L (excl. Protrusions)

Motherboard Support ITX, Micro ATX, ATX, E-ATX (Width up to 296mm w/ SFX PSU, up to 273 w/ ATX PSU)

Expansion Slots 7

3.5" Drive Bays 4

2.5" Drive Bays 3

I/O Panel - USB Ports 2x USB 3.2 Gen 1 Type A, 1x USB 3.2 Gen 2 x 2 Type C

I/O Panel - Audio In / Out 1x 3.5mm Combo

Pre-installed Fans - Rear QUBE 500 Flatpack: 1x 120mm (1800 RPM) SF Black PWM, QUBE 500 Flatpack White: 1x 120mm (1800 RPM) SF White PWM

Fan Support - Front 1x 120/140mm (x2 if PSU is mounted in bottom)

Fan Support - Top 2x 120/140mm

Fan Support - Rear 1x 120mm

Fan Support - Bottom 2x 120/140mm

Fan Support - Left side 2x 120/140mm

Radiator Support - Front 120mm, 140mm, (240/280mm w/ PSU in bottom)

Radiator Support - Top 120mm, 140mm, 240mm, 280mm, (280mm can be used within 53mm thickness)

Radiator Support - Rear 120mm

Radiator Support - Bottom 120mm, 140mm, 240mm, 280mm

Radiator Support - Left side 120mm, 140mm, 240mm, 280mm

Clearance - CPU Cooler 164mm-172mm (Remove the water cooling bracket)

Clearance - PSU 173mm to first GPU slot, 216 maximum space (w/o cable management space), 332mm space mounted in bottom (w/o cable management space)

Clearance - GFX 365mm

Cable Routing - Behind Motherboard Tray 29-32mm

Handle QUBE 500 Flatpack: Black x 1, QUBE 500 Flatpack White: Grey x 1

Gem Mini QUBE 500 Flatpack: Black x 1, QUBE 500 Flatpack White: Grey x 1

Dust Filters Front, Top, Bottom, Right side

Power Supply Support SFX, SFX-L, ATX

Warranty 2 years

Series QUBE Series

Size Mid Tower

Adatok

Gyártó:

COOLER MASTER

Gyártói cikkszám:

Q500-KGNN-S00

Garancia:

24 hónap

EAN:

4719512140383

Gyártó:

COOLER MASTER

Szín:

Fekete

EAN:

4719512140383

PSU/táp:

Nem

FAN/ventilátor:

1
